ZJHK Heavy Duty Power Connector Insert,HK-012/2-FC , 12(Power)+2(Signal) + PE, 40A(Power)/10A(Signal), 690/250V, Female, Crimp Terminal
Part Number | HK-012/2 |
Series | HK Combination Crimp Insert |
Descriptions | Combination Heavy Duty Power Connector Insert, 12 Poles (Power) + 2 Poles (Signal) + PE, 40A/10A, Female, Crimp Terminal |
Gender | Male and Female |
Mating Cycle (Mechanical Working Life) | ≥ 500 |
Size | 16B |
Working Temperature Range | -40℃~125℃ |
Termination Method | Crimp Terminal, Order Crimp Contacts Separately |
Number of Contacts | 12(Power) + 2(Signal) + PE |
Power Contact Rated Current | 40A (Power) |
Power Contact Rated Voltage Acc. to EN61 984 | 690V (Power) |
Power Contact Rated Voltage Acc. to UL/CSA | 600V |
Rated Impulse Voltage | 8KV |
Signal Contact Rating Acc. to EN 61 984 | 10A/250V/4KV |
Signal Contact Rating Acc. to UL/CSA | 300V |
Power and Signal Contact Resistance | ≤ 0.3mΩ |
Insulation Resistance | ≥1010Ω |
Pollution Degree | 3 |
Power Wire Cross Section Range | 1.5mm² – 6mm² |
Power Wire Gauge | AWG16 - AWG10 |
Signal Wire Cross Section Range | 0.14mm² – 2.5mm² |
Signal Wire Gauge | 26 - 14 AWG |
Stripping Length | See Crimp Contact Specs |
Inserts | Polycarbonate(Sabic 3412 ECR) |
Contacts | Hard-Silver Plated Copper Alloy or Hard-Gold Plated Copper Alloy |
Flammability Acc. to UL 94 | V0 |
Inserts Details (L:Female/R:Male)
The new connector is designed of Combination inserts for use in industrial automation and machine building applications where sensor signals need to be terminated alongside power supply conductors and routed via integral signal contacts for connection in a system control unit.
FAQ:
1.Q:Are you manufactory or trade company?
A:We are the manufactory in Wenzhou,Zhejiang Province,China.
2.Q:Can we have our logo or company name to be printed on your products or the package?
A:Sure.OEM is welcomed.Your Logo can be puted on our products.And we can make package according to your design.
3.Q:what’s your advantage compare with Harting、ILME、TE（SIBAS）?
A:Our HDC can replace Harting、ILME、TE（SIBAS）perfectly,most of clients who use those brand before,After the test ,they choose us.Also our price is lower than Harting 40-50%.
4.Q:How's the delivery?Because I really need them is urgently?
A:For sample order 3~7 days will be no problem.And for regular order we promise in 10 days after payment .
