Product Details
ZJHK Modular Frames
Grounding system according to VDE
Die cast zinc construction
Hinged frame (except item type 1 – one piece)
A-B, a-b, A-C, a-c, A-D, a-d, A-F, and a-f orientation available depending on 2, 3, 4, or 6 insert module’ requirement
Mating cycles ≥500
For use in standard hoods and housings,also,ZJHK Hinged frame can match with Harting,ILME,TE.
Gender | Male & Female |
Accessory Type | Frame |
Range | Han Modular frames |
Series | HE-Modular |
For Use With | Standard ZJHK Hoods and Housings |
Description of the accessory | A ... B,A ... C,A ... D,A ... F |
for 2,3,4 or 6 modules | |
Size | 6B,10B,16B,24B |
Limiting temperature | -40 ... +125 °C |
Mating cycles | ≥ 500 |
Material | Zinc die-cast |
RoHS | compliant with exemption |
Packaging size | 2 |
Net weight | 110g |
ZJHK HM® Modular
The modular system (ZJHK - HM) enables signal, power, pneumatic, coax and ethernet connections in one connector in individual customized arrangement.
These in turn may be fitted to standard ZJHK® housings. The system allows a variety of insert configurations within the one connector assembly. The ZJHK-Modular system is designed to meet specific requirements of individual customers and offers flexibility when considering connections for signal, power & pneumatic lines when a solution is required with one connector Apart from the quality of the crimp connector, the right choice of the assembly tool is the basic element of a reliable connection.ZJHK offers appropriate crimping tools for different levels of automation for all connectors.
Module installation and disassembly diagram
