High StructureTop Entry 10B Heavy Duty Connector Hoods
description
The High Structure Top Entry 10B metal hood is a protective housing designed for 10B size heavy-duty connector systems. With its raised structure and top cable outlet configuration, it provides additional internal space for wiring while maintaining reliable mechanical protection in demanding industrial environments.Manufactured from robust metal materials, the hood provides strong resistance to vibration, mechanical stress, and impact, ensuring stable performance in industrial applications.
Tech Spec.
High Structure Hoods
Size
10B
Cable Entry
Top Entry
Material
Alluminium
Colour
Grey
Lever Type
Lever
Material
Mental galvanized
Seal
NBR
Rated Temperature
-40...+125℃
Flammablity acc. To UL 94
V0
Protection Grade
IP65
Part Number
Thread Size
19300100446
M25
19300100447
M32
09300100442
PG21
09300100443
PG29
Product Material
The most significant characteristic of nitrile rubber is its strong oil resistance. It exhibits excellent resistance to mineral oils, lubricating oils, hydraulic oils, and fuel oils, making it ideal for sealing components in mechanical and electrical equipment. In industrial connectors and equipment housings, nitrile rubber seals effectively improve the dustproof, waterproof, and oil-proof properties of products, thereby helping equipment maintain stable operation in complex industrial environments.
details
The elevated housing design offers more room inside the enclosure, allowing thicker cables or more complex insert configurations to be installed with greater ease.The vertical cable outlet enables cables to be routed upward from the connector, making it suitable for installations such as control cabinets or equipment panels where vertical wiring is preferred.
Material: Alluminium
Surface: Powder-coated
Colour: Grey
Limiting Temperature: -40°C to +125°C
Protection Rating: IP65 (according to IEC 60529, when connector is properly coupled)
Thread Type: M / PG
Package and delivery
Package
After passing strict quality inspection, all qualified products are individually packaged to ensure protection during transportation. Each item is carefully labeled, sealed in protective packaging, and then packed into cartons to guarantee product integrity and easy identification.
Delivery
We provide flexible shipping options to meet different customer needs, including international express services such as FedEx and UPS, as well as dedicated sea, land, and air freight lines. Under normal circumstances, orders can be shipped within one week after confirmation, ensuring timely delivery to our customers.
Our factory & quipment
applications
In the fields of industrial automation, power distribution, and process control, control cabinets , as the core unit of the system, undertake important functions such as power distribution, signal control, and equipment protection. With the increasing integration of equipment and the growing complexity of systems, traditional wiring methods are gradually revealing limitations in terms of installation efficiency, maintenance costs, and reliability. Therefore, heavy-duty connectors are becoming an increasingly important component in control cabinet design.
integrated transformers
As industrial power equipment develops towards higher power, higher reliability, modularity, and intelligence , integrated transformers are widely used in frequency converters, inverters, UPS, electric drive systems, and various industrial power supply equipment. In such systems, achieving a safe, reliable, and efficient electrical connection between the transformer and the entire system has become a key aspect of equipment design.
in one-stop service
ZJHK is a staunch leader in the heavy-duty connector market, firmly established in the industry's leading echelon. It has built a complete industrial chain, with products covering multiple series such as HA and HE, with thousands of combinations to cover the needs of multiple sectors.
"For heavy-duty connectors, Haoke is more stable!" is its promise and portrayal. In the future, the company will continue to focus on customer needs and become a trusted choice in the global industrial connectivity field.
