HE Standard Insert, 6 + PE, 16A, Male , Crimp Terminal | |
Note: Crimp contacts need to be ordered separately | |
Type | HE-006-MC&FC |
Series | HE standard terminal |
Certificated | CE,ISO9001,CCC,Rohs,UL |
Data sheet |
|
Feature |
|
Gender | Male&Female |
Service life（Mechanical Working Life） | ≤500 Mating cycle |
Size of shell | H6B |
Working Temperature Range | -40℃...+125℃ |
Termination Method | Crimp terminal |
Number of contacts | 6+PE |
Electrical Data |
|
Rated Current | 16A |
Rated Voltage Acc. to EN61 984 | 500V |
Rated Voltage Acc. to UL/CSA | 600V |
Rated Impulse Voltage | 6KV |
Contact Resistance | <= 3mΩ |
Insulation Resistance | >=1010Ω |
Pollution Degree | Ⅲ |
Wire Cross Section Range | 0.14mm2 – 4.0mm2 |
Wire Gauge | 26 - 12 AWG |
Material |
|
Inserts | Polycarbonate（Sabic） |
Contacts | Hard-Silver Plated Copper Alloy, Hard-Gold Plated Copper Alloy |
Core detail
Drawing of inserts(Male and Female)
ZNJHK crimp terminal connector Constant contact resistance as as result of precisely repeated crimp connection quality.
Corrosion free connections as result of cold weld action.
Pre-preparation of cable forms with crimp contacts fitted,effectively improve wiring efficiency.
