Number of contacts | 12+PE（Grounding） |
Working Current | 10Amp |
Working voltage | 400V |
Rated impulse voltage | 6KV |
Pollution degree 2 also Working voltage | 400/690V |
Insulation resistance | ≥1010Ω |
Material | PolyCarbonate |
Flammability acc.to (UL94) | V0 |
Limiting temperatures | -40 to +125°C |
Mechanical working life (mating cycles) | ≥500 |
Data of contacts | |
Material | Copper alloy |
Surface | Silver plated and Gold plated |
Contact resistance | ≤3mΩ |
Terminal | Crimp terminal |
Wire gauge | 0.14-2.5mm²(AWG26-14) |
PE Wire gauge | 0.5-2.5mm²(AWG20-14) |
Shell size of inserts | ZJHK® H3A |
Note: Order Crimp Contacts Separately
Details
Acceptable wire cross section area:
0.37mm2
0.5mm2
0.75mm2
1.0mm2
1.5mm2
2.5mm2
Crimp connection advantage
