HE Standard Insert, 6 + Ground, 16A, Male and Female , Crimp Terminal
For the crimp connection, the wire connection level is designed as a crimp contact. The established crimp connection has been used as a standard for decades.
Crimp contacts are not delivered with the inserts.
Part Number | HE-006-MC&FC |
Series | HE Standard crimp Insert |
Descriptions | Heavy Duty Power Connector terminal, 6 Poles + PE, 16 A, Crimp Terminal |
Availability | Stock article |
Limit temperature | -40 °C ... 125 °C |
Insulation strength | 1010 Ω |
No. of poles | 6 |
Plugging cycles, gold | ≥ 500 |
Plugging cycles, silver | ≥ 500 |
Pollution severity | 3 |
Rated impulse voltage (DIN EN 61984) | 6 kV |
Size | H6B |
Wire connection cross section AWG, min | AWG 20 |
Wire connection cross section AWG, max. | AWG 12 |
Product type | Inserts |
Type of connection | Crimp connection |
ROHS | Conform |
Details
Design drawing
According to our design drawing you will see our connector can match or replace lot brands of heavy duty connector.
So you don't have worried about the insert does not match or can not replace that you were using .
Contact Us
Do you have questions or suggestions?
Write to us with them. We are here for you.
Hot Tags: industrial air conditioner 6 PIN crimp connector, China, manufacturers, suppliers, factory, Heavy Duty Industrial Module Connector, Insert Crimp Terminal Heavy Duty Connector, Industrial Connector For Automation, Harting Heavy Duty Power Connectors Replace, HEE 092 Pin Crimp Industrial Connector
