H10A-STI
Inserts, Screw termination, Male, Polycarbonate, RAL 7032 (pebble grey), Rated current: 16A, Size: 10 A, Contacts: 10, Conductor cross-section: 0.75 ... 2.5mm², Copper alloy, Silver plated
Part number: 09 20 010 2612
Technical data
| Version | |
Termination method | Screw termination |
Gender | Male&Female |
Size | 10A |
With wire protection | Yes |
Number of contacts | 10 |
PE contact | Yes |
Technical characteristics | |
Conductor cross-section | 0.75 ... 2.5 mm² |
Conductor cross-section | AWG 18 ... AWG 14 |
Rated current | 16A |
Rated voltage | 250 V |
Rated impulse voltage | 6 kV |
Pollution degree | 3 |
Insulation resistance | > 1010 Ω |
Contact resistance | ≤ 1 mΩ |
Limiting temperature | -40 ... +125 °C |
Stripping length | 7.5 mm |
Tightening torque | 0.5 Nm |
Mating cycles | ≥ 500 |
Material properties | |
Material (insert) | Polycarbonate |
Colour (insert) | RAL 7032 (pebble grey) |
Material (contacts) | Copper alloy |
Surface (contacts) | Silver plated |
Commercial data | |
Packaging size | 1 |
Country of origin | China |
European | 85366990 |
Chinese customs tariff number | 8536901900 |
eCl@ss | 27440205 Contact insert for industrial connectors |
Our advantage :
We had 9 years experience at heavy duty connector ,and We had Provided Many companies a variety of industrial solutions.
All the production line is follow Germany standard.
Also, our price is lower than Harting、TE、Weidmuller 40%,but the point is the same quality and fast lead time.
Our inserts can Match with Han E 10 Pos. F&M perfectly.
Please check our design drowing with Harting design drowing
ZJHK
Harting
FAQ:
1. What’s your material for inserts ?
A:In order to guarantee the quality of the products, we use the imported material SABIC 3412 for injection molding.
2.What about SABIC company?
SABIC is a Saudi diversified manufacturing company, active in petrochemicals, chemicals, industrial polymers, fertilizers, and metals. It is the largest public company in the Middle East and Saudi Arabia as listed in Tadawul. 70% of SABIC's shares are owned by Saudi Aramco.
3.Do you have any agent around word?
Yes ,We are honored to be favored by Korean and Italian (Northern) customers and have signed an agency agreement.
4.If we are interested in your heavy duty connector,can we visit your factory ?
Yes. We are normally welcome you visit us and we can learn more from each other.
