Description
introduction
H3A-CCT-1L is a flying wire metal housing specifically designed for the Heavy-Duty Connector Series A, with a rated size of 3A. Its key feature is the dual outlet design, enabling flexible wiring adaptation to various scenarios. Boasting a stable structure and reliable protection performance, this housing is widely used in industrial automation, mechanical equipment, power systems and other fields, providing stable support for connection systems.
Parameters
SeriesA Hoods
Size
3A
Cable Entry
Cable to cable
Material
Zinc die-cast
Colour
Grey
Locking Element
Lever Type
Lever
Material
Mental galvanized/nickel plating
Hoods Seal
NBR
Limiting Temperature
-40...+125℃
Flammablity acc. To UL 94
V0
Degree of Protection
IP65
Thread Size
Part Number
M20
19200031750
PG11
09200031750
PG13.5
09200031751
Products overview
H3A-CCT-1L
The H3A-CCT-1L heavy-duty connector housing is integrally formed with high-quality zinc alloy, featuring a sturdy and corrosion-resistant structure. It is equipped with a durable iron buckle for easy installation and secure locking. The sealing ring is made of high-grade rubber with excellent sealing performance, and combined with a precision structural design, the product achieves an IP65 waterproof rating, effectively resisting dust, splashing water and other external environmental impacts to adapt to complex working conditions.
Material: zincdie-cast
Surface: powder-coated
Colour:(grey)-Temperature range: -40℃-+125℃-
Degree of Protection: IP65(acc.to lEC 60529 for coupled connector)
Locking element:
locking type: single locking latch
material: stainless steel
Cable entry: top entry
No,of cable entries: 1
Thread Size: M20/PG11/PG13.5
01
High Quality
02
Advanced Equipment
03
Professional Team
04
Custom Service
Compatible Inserts
Choose the plan that suits you best.
hA-003-MS/FS
Current Ampere: 10A
Current Voltage: 250V
Contacts Number: 3
Cage-clamp Termianl
hA-004-M/F
Current Ampere: 10A
Current Voltage: 250V
Contacts Number: 4
Screw Terminal
hD-007-mC/FC
Current Ampere: 10A
Current Voltage: 250V
Contacts Number: 7
Crimp Terminal
HD-008-MC/FC
Current Ampere: 10A
Current Voltage: 250V
Contacts Number: 8
Crimp Terminal
applications
As the printing industry upgrades to "intelligent, green, and high-speed", the application of heavy-duty connectors will show the following three trends:Miniaturization and High Density : As printing machines evolve toward more compact designs (such as narrow-web digital printing presses), connector size requirements are increasing. The next generation of heavy-duty connectors will adopt a "high-density contact" design, reducing size while maintaining multi-signal integrated transmission capabilities to meet the connection needs of miniaturized devices.
battery energy storage system
From the perspective of power transmission, heavy-duty connectors can withstand high current and high power transmission tasks, providing stable power support for equipment under high load conditions, ensuring the continuity of production activities. In terms of signal transmission, they can accurately transmit control signals, data signals, and sensor signals, laying the foundation for the precise operation of automated control systems. Due to their excellent performance, heavy-duty connectors are widely used in various industries.
With the advantages of full categories and stable quality, ZJHK sales performance continues to grow steadily, which is backed by the high recognition of the market and customers. In the precise connection of automated production lines, in the harsh working conditions of construction machinery, and under the high-frequency operation of logistics equipment, ZJHK heavy-duty connectors always aim at "zero failure" and use stable performance to safeguard customers' production efficiency."For heavy-duty connectors, ZJHK is more stable!"ZJHK Electric will continue to focus on customer needs and become a trusted choice in the field of global industrial connections with richer products and more reliable performance.
